GaN Power, the new charging technology:
Compared to traditional silicon-based chargers, GaN (gallium nitride) is a new semiconductor material that provides more energy in a smaller size, effectively increasing the charge and generating less heat.
Safe and robust design:
Light, compact and easy to carry. It includes internal protection mechanisms for overvoltage, overheating, short circuit, fluctuating power supply, power failure and voltage drop and ensures the safety of charging.
100W charging power:
When charging a device, it can deliver more than 100W of power, with the charging values in the table.
| USB-C Protocols |
PD3.0/ PPS/ PD2.0/ QC3.0/ QC2.0/ AFC/ FCP |
| USB-A Protocols |
SCP/FCP/QC3.0/QC2.0/Apple 2.4A |
| USB-C1 output (100W Max) |
PD:5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/5A |
| PPS 3.3-21V/3A |
| USB-C2 output (100W Max) |
PD:5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/5A |
| PPS 3.3-21V/3A |
| USB-C3 output (20W Max) |
5V/3A, 9V/2.22A,12V/1.5A |
| USB-A output (22.5W Max） |
4.5V/5A, 5V/4.5A, 9V/2A, 12V/1.5A |
| USB-C1 + USB-C2 Output |
60W + 30W |
| USB-C1 + USB-C3 Output |
60W + 20W |
| USB-C1 + USB-A1 Output |
60W + 22.5W |
|
USB-C2 + USB-C3 Output
|
45W + 20W |
| USB-C2 + USB-A1 Output |
45W + 22.5W |
| USB-C3 + USB-A1 Output |
5V/2A + 5V/2A |
| USB-C1+USB-C2+USB-C3 Output |
45W + 30W + 20W |
| USB-C1+USB-C2+USB-A1 Output |
45W + 30W + 22.5W |
| USB-C1+USB-C3+USB-A1 Output |
60W + 5V/2A + 5V/2A |
| USB-C2+USB-C3+USB-A1 Output |
45W + 5V/2A + 5V/2A |
| USB-C1+USB-C2+USB-C3+USB-A1 Output |
45W + 30W + 5V/2A + 5V/2A |
